We pursue the management tenet of “Quality is top-quality, Company is supreme, Status is first”, and will sincerely create and share success with all shoppers for OEM Factory for Thermal Pump R32 Natural Green Refrigerant Swimming Pool Heatpumps Inverter for Residential Hotel Gym Pool Water Heating and Cooling, We maintain timely delivery schedules, revolutionary designs, high-quality and transparency for our buyers. Our moto would be to provide top quality goods within just stipulated time.
We pursue the management tenet of “Quality is top-quality, Company is supreme, Status is first”, and will sincerely create and share success with all shoppers for R32 Swimming Pool Heat Pump and Heating Pump for Swimming Pool, we’ve been sincerely hope to establish one good long term business relationship with your esteemed company thought this opportunity, based on equal, mutual beneficial and win win business from now till the future.
Unit Parameter Table | |||
Air-cooled Module Unit Parameter Table | |||
Unit Type Unit parameters |
ZGR-65ⅡAG2 | ZGR-130ⅡAG2 | |
Rated Refrigeration (A35/W7℃) |
Cooling Capacity(kW) | 65 | 130 |
Power(kW) | 20.3 | 40.6 | |
EER | 3.20 | 3.20 | |
Rated Heating (A7/W45℃) |
Heating Capacity(kW) | 70 | 140 |
Power(kW) | 20.5 | 41.0 | |
COP | 3.41 | 3.41 | |
Mains | 380V/3N~/50Hz | ||
Maximum Operating Current(A) | 58 | 115 | |
Cooling Operating Ambient Temperature Range(℃) | 16~49 | ||
Heating Operating Ambient Temperature Range(℃) | -15~28 | ||
Cooling Water Temperature(℃) | 5~25 | ||
Heating Water Temperature(℃) | 30~50 | ||
Refrigerant | R410A | ||
Safeguard | Higher-lower voltage protection, antifreeze protection, overload, water flow protection, etc. | ||
Capacity Adjustment Method | 0~100% | 0~50%~100% | |
Throttling Method | Electronic Expansion Valve | ||
Water Side Heat Exchanger | Shell and Tube Heat Exchanger | ||
Wind Side Heat Exchanger | High-efficiency Finned Tube Heat Exchanger | ||
Fan | High Efficiency and Low Noise Axial Flow Fan | ||
Water System | Chilled Water Flow(m³/h) | 11.2 | 22.4 |
Hydraulic Pressure Drop(kpa) | 40 | 75 | |
Maximum Working Pressure(Mpa) | 1.0 | ||
Water Pipe Connection | DN65(Flange) | DN80(Flange) | |
Anti-shock Protection Type | Ⅰ | ||
Waterproof Level | IPX4 | ||
Dimentions | Length(mm) | 1930 | 2340 |
Width(mm) | 941 | 1500 | |
Height(mm) | 2135 | 2350 | |
Weight(kg) | 590 | 1000 | |
Rated refrigeration: outdoor dry/wet bulb temperature is 35°C/24°C; outlet water temperature: 7°C | |||
Rated heating: outdoor dry/wet bulb temperature is 7℃/6℃; outlet water temperature is: 45℃ | |||
Models, parameters, and performance will be changed due to product improvements. Please refer to the actual product and nameplate for specific parameters; | |||
Executive Standard:GB/T 18430.1(2)-2007 GB/T 25127.1(2)-2010 |
Introducing our latest innovation in energy-efficient heating and cooling technology – the OEM Factory Heat Pump R32 Natural Green Refrigerant Swimming Pool Heat Pump Inverter. Designed for heating and cooling residential, hotel and gym pool water, this state-of-the-art heat pump is designed to revolutionize the way you keep your pool temperature.
At the heart of this cutting-edge product is the use of R32 Natural Green Refrigerant, which not only provides superior thermal performance but also significantly reduces environmental impact. This makes our heat pumps an environmentally friendly choice for those who are concerned about their carbon footprint and want to contribute to a greener future.
Our heat pumps use inverter technology to ensure precise control of the heating and cooling process, resulting in optimal energy efficiency and cost savings. Whether you want to heat your pool in the colder months or cool it down in the hot summer months, our heat pumps offer the flexibility and reliability you need.
One of the main benefits of our heat pumps is their quiet operation, making them ideal for residential environments with high levels of noise pollution. Additionally, their compact design and simple installation make them a hassle-free addition to any pool system, whether new or retrofitted.
With a focus on performance, sustainability and user convenience, our OEM factory heat pump R32 natural green refrigerant pool heat pump inverter is the perfect choice for anyone looking for a reliable, efficient solution for heating and cooling pool water. Say goodbye to traditional, energy-consuming heating methods and hello to the future of pool temperature control with our innovative heat pumps.
Experience the difference our heat pumps can make for your pool today. Join the ranks of environmentally conscious pool owners and enjoy the benefits of sustainable, cost-effective and reliable pool temperature management.
