How to quickly locate and solve the failure point of the refrigeration system? ?

When the refrigeration system breaks down, generally the faulty part cannot be seen directly, because it is impossible to disassemble and dissect the components of the refrigeration system one by one, so it can only be checked from the outside to find out the abnormal phenomenon in operation and conduct a comprehensive analysis. During the inspection, the operating status of the system is generally understood by looking, listening, and touching. When the operating pressure and temperature of the system exceed the normal range, in addition to the deterioration of the indoor and outdoor ambient temperature, there must be a problem, which is an important basis for judging the root cause of the fault.

The temperature in the refrigeration system involves a wide range, including evaporation temperature te, suction temperature ts, condensation temperature, exhaust temperature, etc.; the evaporation temperature te and condensation temperature tc play a decisive role in the operating conditions of the refrigeration system. The detection of these temperatures is very important to the inspection of the refrigeration system, but these temperatures can only be estimated by hand feeling in the past, and then judge whether it is normal. This detection method is often inaccurate and dangerous. Imaging technology for non-destructive safety inspection!

”"

Thermal imaging cameras can see the temperature of various components of the refrigeration system

To detect and solve problems in time

Ensure the normal operation of the refrigeration system and the safety of testing personnel

But for narrow, occluded detection areas

Ordinary thermal imaging cameras may not be able to accurately detect

However, Phil’s recently launched

Detachable new intelligent thermal imaging camera

FLIR ONE Edge Pro

Can meet the refrigeration system equipment testing process

Requirements such as narrow areas, high occlusions, changeable detection directions, etc.

During the inspection of the refrigeration system, since the refrigerant, compressor, evaporator, restrictor, condenser and other equipment cannot be completely disassembled, there must be a narrow area that is difficult to reach, and there may be shelter. Scanning inspection results may not be ideal, so if the thermal imager can be placed in a more internal position, the inspection details will be clearer and it will be easier to improve inspection efficiency!

The FLIR ONE Edge Pro mobile phone thermal imaging camera adopts a separate design, allowing users to hold the thermal imager in one hand and a smart device (iOS, Android smartphones and tablet computers, etc.) 35mm×149mm), and weighs only 153g. During the inspection of the refrigeration system, facing the difficult-to-access areas such as evaporators and condensers, you only need to extend the lens of the thermal imager in, and you can extend your eyes into it. Visually observe the interior through smart devices to understand the specific location of the fault. It is light in weight and will not be tired after long-term operation.
