Factory Cheap Box Type Refrigeration Scroll Compressor Condensing Units for Blast Freezer Room

Short Description:

Bitzer Semi-closed Piston Condensing Unit5

Suitable for: Supermarket, Shopping mall, Cold storage, Freezer, Processing room, Laboratory, Cold storage logistics.

◾ 2hp-9hp, a large range to choose from
◾ Adopt international brand Bitzer original compressor, high efficiency and energy saving
◾ The whole unit or split unit can be selected according to the needs of the store (condenser and unit are integrated or separated)
◾ High quality components of world famous brands
◾ Effective air-cooled condenser which enables high energy efficiency ratio
◾ Compact structure; sturdy and durable; convenient to install
◾ Widely applicable and can be applied to refrigerants R22,R134a, R404a, R507a, etc.

Send email to us

Product Detail

Product Tags

Our concentrate on should be to consolidate and enhance the quality and service of present products, meanwhile consistently produce new products to meet unique customers’ demands for Factory Cheap Box Type Refrigeration Scroll Compressor Condensing Units for Blast Freezer Room, Adhering to your small business philosophy of ‘customer first, forge ahead’, we sincerely welcome clientele from at your house and abroad to cooperate with us.
Our concentrate on should be to consolidate and enhance the quality and service of present products, meanwhile consistently produce new products to meet unique customers’ demands for China Air Cooling and Air Cooled, Wide selection and fast delivery for you! Our philosophy: Good quality, great service, keep improving. We are looking forward that more and more oversea friends join in our family for further development near the future!

box type copeland scroll condensing units parameters

HP	KW	Condensing temperature(℃)	Evaporation temperature(℃)
HP	KW	Condensing temperature(℃)	-12	-10	-8	-5	0	5	10
2	Q	30	3.37	3.71	4.01	4.47	5.37	6.37	7.46
		40	3.04	3.33	3.61	4.04	4.89	5.80	6.89
		45	2.78	3.04	3.35	3.82	4.61	5.49	6.53
		50	2.52	2.76	3.10	3.61	4.32	5.18	6.18
	P	30	1.19	1.19	1.19	1.20	1.22	1.25	1.28
		40	1.45	1.45	1.45	1.47	1.49	1.51	1.52
		45	1.61	1.61	1.62	1.63	1.65	1.67	1.68
		50	1.78	1.78	1.78	1.80	1.82	1.84	1.85
2.5	Q	30	3.90	4.23	4.61	5.18	6.18	7.32	8.60
		40	3.52	3.85	4.17	4.66	5.61	6.70	7.93
		45	3.21	3.49	3.85	4.39	5.30	6.34	7.53
		50	2.90	3.14	3.53	4.13	4.99	5.99	7.13
	P	30	1.34	1.34	1.34	1.35	1.38	1.41	1.44
		40	1.64	1.64	1.64	1.65	1.67	1.70	1.72
		45	1.82	1.82	1.83	1.84	1.86	1.88	1.90
		50	2.01	2.01	2.01	2.03	2.05	2.07	2.08
3	Q	30	4.94	5.37	5.82	6.51	7.79	9.22	10.88
		40	4.42	4.85	5.26	5.89	7.08	8.46	9.98
		45	4.01	4.42	4.87	5.56	6.70	8.00	9.48
		50	3.61	3.99	4.48	5.23	6.32	7.55	8.98
	P	30	1.71	1.71	1.71	1.72	1.76	1.80	1.83
		40	2.10	2.09	2.09	2.11	2.14	2.18	2.20
		45	2.34	2.33	2.34	2.35	2.38	2.42	2.43
		50	2.58	2.58	2.58	2.60	2.63	2.66	2.67
4	Q	30	6.60	7.17	7.80	8.74	10.45	12.35	14.58
		40	5.94	6.46	7.03	7.89	9.50	11.31	13.40
		45	5.39	5.89	6.52	7.46	8.98	10.71	12.73
		50	4.85	5.32	6.00	7.03	8.46	10.12	12.07
	P	30	2.15	2.14	2.14	2.16	2.21	2.26	2.31
		40	2.64	2.64	2.64	2.66	2.70	2.74	2.77
		45	2.94	2.95	2.96	2.97	3.01	3.05	3.07
		50	3.25	3.26	3.27	3.29	3.33	3.36	3.38
5	Q	30	8.22	8.93	9.69	10.83	12.97	15.34	18.10
		40	7.36	8.03	8.73	9.79	11.78	14.06	16.67
		45	6.70	7.32	8.09	9.26	11.14	13.32	15.82
		50	6.03	6.60	7.46	8.74	10.50	12.59	14.96
	P	30	2.77	2.77	2.78	2.80	2.85	2.92	2.98
		40	3.40	3.40	3.41	3.42	3.48	3.53	3.56
		45	3.79	3.79	3.80	3.82	3.87	3.92	3.95
		50	4.17	4.18	4.19	4.21	4.26	4.31	4.33
6	Q	30	9.93	10.78	11.68	13.02	15.58	18.53	21.95
		40	8.98	9.79	10.62	11.88	14.20	16.91	20.05
		45	8.12	8.88	9.81	11.21	13.47	16.06	19.02
		50	7.27	7.98	9.01	10.55	12.73	15.20	18.00
	P	30	3.14	3.16	3.18	3.20	3.24	3.29	3.36
		40	3.90	3.92	3.93	3.95	3.98	4.00	4.04
		45	4.37	4.40	4.41	4.43	4.45	4.46	4.49
		50	4.84	4.87	4.88	4.90	4.91	4.92	4.94
7	Q	30	10.93	11.83	12.82	14.31	17.15	20.38	24.13
		40	9.88	10.74	11.65	13.02	15.63	18.62	22.04
		45	8.93	9.76	10.78	12.30	14.80	17.65	20.92
		50	7.98	8.79	9.91	11.59	13.97	16.67	19.81
	P	30	3.44	3.46	3.48	3.50	3.54	3.59	3.68
		40	4.27	4.29	4.31	4.33	4.35	4.38	4.43
		45	4.79	4.81	4.83	4.85	4.87	4.89	4.92
		50	5.31	5.33	5.35	5.37	5.39	5.39	5.41
9	Q	30	16.01	17.86	19.28	21.42	25.56	30.31
		45	12.76	14.25	15.37	17.05	20.29	23.97
		50	11.60	12.97	13.99	15.53	18.48	21.80
	P	30	5.37	5.42	5.46	5.51	5.62	5.75
		40	6.62	6.66	6.68	6.71	6.78	6.87
		45	7.44	7.47	7.48	7.51	7.55	7.61
		50	8.25	8.27	8.28	8.30	8.32	8.35

Long life
—With high efficient and long life copper-aluminum fin type heat exchanger.

Low noise
—Low noise and high efficient external rotor fan motor.
—With world famous brand compressor,small vibration,low noise and reliable operation.

Easy connection
—System with water-proof cable connection box for easy connection.
