box type emerson copeland scroll condensing units

Short Description:

Bitzer Semi-closed Piston Condensing Unit5

Suitable for: Supermarket, Shopping mall, Cold storage, Freezer, Processing room, Laboratory, Cold storage logistics.

◾ 2hp-9hp, a large range to choose from
◾ Adopt international brand Bitzer original compressor, high efficiency and energy saving
◾ The whole unit or split unit can be selected according to the needs of the store (condenser and unit are integrated or separated)
◾ High quality components of world famous brands
◾ Effective air-cooled condenser which enables high energy efficiency ratio
◾ Compact structure; sturdy and durable; convenient to install
◾ Widely applicable and can be applied to refrigerants R22,R134a, R404a, R507a, etc.

Send email to us

Product Detail

Product Tags

box type copeland scroll condensing units parameters

HP	KW	Condensing temperature(℃)	Evaporation temperature(℃)
HP	KW	Condensing temperature(℃)	-12	-10	-8	-5	0	5	10
2	Q	30	3.37	3.71	4.01	4.47	5.37	6.37	7.46
		40	3.04	3.33	3.61	4.04	4.89	5.80	6.89
		45	2.78	3.04	3.35	3.82	4.61	5.49	6.53
		50	2.52	2.76	3.10	3.61	4.32	5.18	6.18
	P	30	1.19	1.19	1.19	1.20	1.22	1.25	1.28
		40	1.45	1.45	1.45	1.47	1.49	1.51	1.52
		45	1.61	1.61	1.62	1.63	1.65	1.67	1.68
		50	1.78	1.78	1.78	1.80	1.82	1.84	1.85
2.5	Q	30	3.90	4.23	4.61	5.18	6.18	7.32	8.60
		40	3.52	3.85	4.17	4.66	5.61	6.70	7.93
		45	3.21	3.49	3.85	4.39	5.30	6.34	7.53
		50	2.90	3.14	3.53	4.13	4.99	5.99	7.13
	P	30	1.34	1.34	1.34	1.35	1.38	1.41	1.44
		40	1.64	1.64	1.64	1.65	1.67	1.70	1.72
		45	1.82	1.82	1.83	1.84	1.86	1.88	1.90
		50	2.01	2.01	2.01	2.03	2.05	2.07	2.08
3	Q	30	4.94	5.37	5.82	6.51	7.79	9.22	10.88
		40	4.42	4.85	5.26	5.89	7.08	8.46	9.98
		45	4.01	4.42	4.87	5.56	6.70	8.00	9.48
		50	3.61	3.99	4.48	5.23	6.32	7.55	8.98
	P	30	1.71	1.71	1.71	1.72	1.76	1.80	1.83
		40	2.10	2.09	2.09	2.11	2.14	2.18	2.20
		45	2.34	2.33	2.34	2.35	2.38	2.42	2.43
		50	2.58	2.58	2.58	2.60	2.63	2.66	2.67
4	Q	30	6.60	7.17	7.80	8.74	10.45	12.35	14.58
		40	5.94	6.46	7.03	7.89	9.50	11.31	13.40
		45	5.39	5.89	6.52	7.46	8.98	10.71	12.73
		50	4.85	5.32	6.00	7.03	8.46	10.12	12.07
	P	30	2.15	2.14	2.14	2.16	2.21	2.26	2.31
		40	2.64	2.64	2.64	2.66	2.70	2.74	2.77
		45	2.94	2.95	2.96	2.97	3.01	3.05	3.07
		50	3.25	3.26	3.27	3.29	3.33	3.36	3.38
5	Q	30	8.22	8.93	9.69	10.83	12.97	15.34	18.10
		40	7.36	8.03	8.73	9.79	11.78	14.06	16.67
		45	6.70	7.32	8.09	9.26	11.14	13.32	15.82
		50	6.03	6.60	7.46	8.74	10.50	12.59	14.96
	P	30	2.77	2.77	2.78	2.80	2.85	2.92	2.98
		40	3.40	3.40	3.41	3.42	3.48	3.53	3.56
		45	3.79	3.79	3.80	3.82	3.87	3.92	3.95
		50	4.17	4.18	4.19	4.21	4.26	4.31	4.33
6	Q	30	9.93	10.78	11.68	13.02	15.58	18.53	21.95
		40	8.98	9.79	10.62	11.88	14.20	16.91	20.05
		45	8.12	8.88	9.81	11.21	13.47	16.06	19.02
		50	7.27	7.98	9.01	10.55	12.73	15.20	18.00
	P	30	3.14	3.16	3.18	3.20	3.24	3.29	3.36
		40	3.90	3.92	3.93	3.95	3.98	4.00	4.04
		45	4.37	4.40	4.41	4.43	4.45	4.46	4.49
		50	4.84	4.87	4.88	4.90	4.91	4.92	4.94
7	Q	30	10.93	11.83	12.82	14.31	17.15	20.38	24.13
		40	9.88	10.74	11.65	13.02	15.63	18.62	22.04
		45	8.93	9.76	10.78	12.30	14.80	17.65	20.92
		50	7.98	8.79	9.91	11.59	13.97	16.67	19.81
	P	30	3.44	3.46	3.48	3.50	3.54	3.59	3.68
		40	4.27	4.29	4.31	4.33	4.35	4.38	4.43
		45	4.79	4.81	4.83	4.85	4.87	4.89	4.92
		50	5.31	5.33	5.35	5.37	5.39	5.39	5.41
9	Q	30	16.01	17.86	19.28	21.42	25.56	30.31
		45	12.76	14.25	15.37	17.05	20.29	23.97
		50	11.60	12.97	13.99	15.53	18.48	21.80
	P	30	5.37	5.42	5.46	5.51	5.62	5.75
		40	6.62	6.66	6.68	6.71	6.78	6.87
		45	7.44	7.47	7.48	7.51	7.55	7.61
		50	8.25	8.27	8.28	8.30	8.32	8.35

Long life
---With high efficient and long life copper-aluminum fin type heat exchanger.

Low noise
---Low noise and high efficient external rotor fan motor.
---With world famous brand compressor,small vibration,low noise and reliable operation.

Easy connection
---System with water-proof cable connection box for easy connection.
