2019 New Style Best Pool Heat Pump Water Heater 2.6

Short Description:

Send email to us

Product Detail

Product Tags

Quality First,and Customer Supreme is our guideline to provide the best service to our customers.Nowadays, we are trying our best to become one of the best exporters in our field to meet customers more need for 2019 New Style Best Pool Heat Pump Water Heater 2.6, We sincerely be expecting exchange and cooperation with you. Allow us to move forward hand in hand and accomplish win-win circumstance.
Quality First,and Customer Supreme is our guideline to provide the best service to our customers.Nowadays, we are trying our best to become one of the best exporters in our field to meet customers more need for 20 Kw Input Power, They’re durable modeling and promoting well all over the world. Under no circumstances disappearing key functions in a brief time, it’s a ought to in your case personally of fantastic quality. Guided by the principle of Prudence, Efficiency, Union and Innovation. the business make an awesome efforts to expand its international trade, raise its enterprise. rofit and improve its export scale. We’re confident that we are going to have a vibrant prospect and to be distributed all over the world in the years to come.

Parameter

Unit Parameter Table
Air-cooled Module Unit Parameter Table
Unit Type Unit parameters		ZGR-65ⅡAG2	ZGR-130ⅡAG2
Rated Refrigeration (A35/W7℃）	Cooling Capacity（kW）	65	130
	Power（kW）	20.3	40.6
	EER	3.20	3.20
Rated Heating (A7/W45℃）	Heating Capacity（kW）	70	140
	Power（kW）	20.5	41.0
	COP	3.41	3.41
Mains		380V/3N~/50Hz
Maximum Operating Current（A）		58	115
Cooling Operating Ambient Temperature Range（℃）		16~49
Heating Operating Ambient Temperature Range（℃）		-15~28
Cooling Water Temperature（℃）		5~25
Heating Water Temperature（℃）		30~50
Refrigerant		R410A
Safeguard		Higher-lower voltage protection, antifreeze protection, overload, water flow protection, etc.
Capacity Adjustment Method		0~100%	0~50%~100%
Throttling Method		Electronic Expansion Valve
Water Side Heat Exchanger		Shell and Tube Heat Exchanger
Wind Side Heat Exchanger		High-efficiency Finned Tube Heat Exchanger
Fan		High Efficiency and Low Noise Axial Flow Fan
Water System	Chilled Water Flow(m³/h)	11.2	22.4
	Hydraulic Pressure Drop(kpa)	40	75
	Maximum Working Pressure(Mpa)	1.0
	Water Pipe Connection	DN65(Flange)	DN80(Flange)
Anti-shock Protection Type		Ⅰ
Waterproof Level		IPX4
Dimentions	Length(mm)	1930	2340
	Width(mm)	941	1500
	Height(mm)	2135	2350
Weight(kg)		590	1000
Rated refrigeration: outdoor dry/wet bulb temperature is 35°C/24°C; outlet water temperature: 7°C
Rated heating: outdoor dry/wet bulb temperature is 7℃/6℃; outlet water temperature is: 45℃
Models, parameters, and performance will be changed due to product improvements. Please refer to the actual product and nameplate for specific parameters;
Executive Standard:GB/T 18430.1(2)-2007 GB/T 25127.1(2)-2010

Quality First,and Customer Supreme is our guideline to provide the best service to our customers.Nowadays, we are trying our best to become one of the best exporters in our field to meet customers more need for 2019 New Style Best Pool Heat Pump Water Heater 2.6, We sincerely be expecting exchange and cooperation with you. Allow us to move forward hand in hand and accomplish win-win circumstance.
2019 New Style 20 Kw Input Power, They’re durable modeling and promoting well all over the world. Under no circumstances disappearing key functions in a brief time, it’s a ought to in your case personally of fantastic quality. Guided by the principle of Prudence, Efficiency, Union and Innovation. the business make an awesome efforts to expand its international trade, raise its enterprise. rofit and improve its export scale. We’re confident that we are going to have a vibrant prospect and to be distributed all over the world in the years to come.
